Wi-Tek WI-POE61-24V

Wi-Tek WI-POE61-24V Gigabit 48VDC PoE to 24VDC PoE Converter – Industrial – Plug n Play – Supports DC 36-60V Input

SKU: WI-POE61-24V Categories: , Tags: , , , , , , ,

Wi-Tek WI-POE61-24V Gigabit 48VDC PoE to 24VDC PoE Converter – Industrial – Plug n Play – Supports DC 36-60V Input

Features :-

  • 2 * 1000Mbps RJ45 Ports with 1x 48V PoE IN, 1x 24V PoE Out
  • Support Passive PoE 24V Output
  • Supports DC 36-60V Input
  • Delivers power up to 100 meters
  • Auto-determine the necessary power requirements
  • Plug-and-Play, requires no configuration
  • Short Circuit Protection

Wi-Tek Product-Link -> WI-POE61-24V



HARDWARE FEATURES

WI-PoE61-24V

Hardware Version

V1

L2 Managed

No

Interface

2 100/1000Mbps  RJ45  Ports

PoE Port

PoE IN: 802.3af/at 48-52V

PoE OUT: Passive 24V

Network Media

10BASE-T: UTP category 3, 4, 5 cable (maximum 100m)

100BASE-TX/1000Base-T: UTP category 5, 5e, 6 or above cable (maximum 100m)

1000BASE-X: MMF, SMF 1000Base-L X:62.5μm/50μm MM(2m~550m) or 10μm SMF(2m~5000m)

Fan Quantity

Fanless

Power Consumption

24W

External Power Supply

DC IN  36-60V

PoE IN 48V

Exchange Capacity

2Gbps

Packet Forwarding Rate

1.49Mpps

Mac Address Table

2K

Packet Buffer Memory

1Mb

Jumbo Frame

10240 Bytes

Protection Level

4kV Lightning protection

4kV ESD Contact discharge

Transmission Method

 Store-and-Forward

 Advanced Functions

Mac Address Auto-Learning And Auto-Aging

Store and forward

IEEE 802.3x  flow control for

Full-duplex Mode

Backpressure for Half-duplex Mode

OTHERS

Certification

CE, FCC, RoHS

Package Dimension

125×97×40 mm

Switch Dimension

85×87×30 mm

Gross Weight

0.19kg

Net Weight

0.15kg

Package Contents

1× PoE Injector

1× Installation Guide

Working Environment

Operating Temperature:

-10°C~70°C
