HiLook DVR-204U-M1 4-Channel Deep Learning Turbo-HD Pentabrid (HDTVI / HDCVI / AHD/ CVBS / IP) 1U Digital Video Recorder

Features :-

  • Deep learning based human and vehicle targets classification of Motion Detection 2.0
  • H.265 Pro+ / H.265 Pro / H.265 video compression
  • HDTVI / AHD / CVI / CVBS / IP video inputs
  • Audio via coaxial cable
  • Up to 6-ch IP camera inputs (up to 8MP)
  • Up to 8MP @ 8fps encoding capability

Motion Detection 2.0

  • Human / Vehicle Analysis: Deep learning-based motion detection 2.0 is enabled by default for all analog channels, it can classify human and vehicle, and extremely reduce false alarms caused by objects like leaves and lights; Quick search by object or event type is supported

Recording

  • Video Compression: H.265 Pro+ / H.265 Pro / H.265 / H.264+ / H.264
  • Encoding Resolution: 8MP / 5MP / 3K / 4MP / 3MP / 1080p / 720p / WD1 / 4CIF / VGA / CIF
  • Frame Rate:
    • Main stream: 8MP @ 8fps / 3K @ 12fps / 5MP @ 12fps / 4MP @ 15fps / 8MP Lite @ 15fps / 3MP @ 18fps  / 1080p / 720p / WD1 / 4CIF / VGA / CIF @ 25fps (P)/30 fps (N)
    • Sub-stream: WD1 / 4CIF / CIF @ 25fps (P)/30 fps (N)
  • Video Bitrate: 32 Kbps to 10 Mbps
  • Dual-Stream: Support
  • Stream Type: Video, Video & Audio
  • Audio Compression: G.711u
  • Audio Bitrate: 64 Kbps

Video And Audio

  • IP Video Input: 2-ch (up to 6-ch)
    • Enhanced IP mode on: 4-ch (up to 8-ch), each up to 4 Mbps Up to 8 MP resolution
    • Support H.265+/H.265/H.264+/H.264 IP cameras
  • Analog Video Input: 4-ch BNC interface (1.0 Vp-p, 75 Ω), supporting coaxitron connection
  • HDTVI Input: 8MP (3840 × 2160) @ 15fps, 8MP (3840 × 2160) @ 12fps, 3K (2960 x 1665) @ 20fps, 5MP (2560 × 1944) @ 20fps, 5 MP (2560 × 1944) @ 12fps, 4MP (2560 × 1440) @ 30fps, 4MP (2560 × 1440) @ 25fps, 3MP @ 18fps,1080p @ 30fps, 1080p @ 25 fps,720p @ 30fps, 720p @ 25fps
  • AHD Input: 5MP (2560 × 1944) @ 20fps, 5MP (2560 × 1944) @ 12fps, 4MP (2560 × 1440) @ 30fps, 4MP (2560 × 1440) @ 25fps, 1080p @ 30fps, 1080p @ 25fps, 720p @ 30fps, 720p @ 25fps
  • HDCVI Input: 8MP (3840 × 2160) @ 15fps, 8MP (3840 × 2160) @ 12fps, 5MP (2592 × 1944) @ 20fps, 4MP (2560 × 1440) @ 30 fps, 4MP (2560 × 1440) @ 25fps, 1080p @ 30fps, 1080p @ 25fps, 720p @ 30fps, 720p @ 25fps
  • CVBS Input: PAL / NTSC
  • HDMI Output: 1-ch, 1920 × 1080/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz
  • VGA Output: 1-ch, 1920 × 1080/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz
  • Video Output Mode: HDMI / VGA simultaneous output
  • Audio Input: 1-ch, RCA (2.0 Vp-p, 1 KΩ); 4-ch via coaxial cable
  • Audio Output: 1-ch, RCA (Linear, 1 KΩ)
  • Two-Way Audio: 1-ch, RCA (2.0 Vp-p, 1 KΩ) (using the first audio input)
  • Synchronous Playback: 4-ch

Network

  • Total Bandwidth: 96 Mbps
  • Remote Connection: 32
  • Network Protocol: TCP/IP, PPPoE, DHCP, HiLookVision, DNS, DDNS, NTP, SADP, NFS, iSCSI, UPnP™, HTTPS, ONVIF
  • Network Interface: 1, RJ45 10M/100M self-adaptive Ethernet interfac
  • Wi-Fi: Connectable to Wi-Fi network by Wi-Fi dongle through USB interface

Auxiliary Interface

  • SATA: 1 SATA interface
  • Capacity: Up to 10 TB capacity for each disk
  • Alarm In/Out: N/A
  • USB Interface: 2 × USB 2.0

General

  • Power Supply: 12 VDC, 1.5 A
  • Consumption: ≤ 15 W (without HDD)
  • Working Temperature: -10 °C to +55 °C (+14 °F to +131 °F)
  • Working Humidity: 10% to 90%
  • Dimension (W × D × H): 265 × 225 × 48 mm (10.4 × 8.9 × 1.9 inch)
  • Weight: ≤ 1.16 kg (without HDD, 2.6 lb.)
BNC Video Input

4 Channel

Additional IP Channels

4

AHD Max Res

5MP

HDCVI Max Res

4MP

HDTVI Max Res

5MP

Input Voltage

12VDC

IP Max Res

8MP

Max. Number of IP Channels

8

Network

Fast Ethernet

PoE Ports Onboard

N/A

Recorder Protocol Support

AHD, Analogue, HDCVI, HDTVI, IP

Recorder Series

Value Series

SATA Ports

1 SATA Port

Surveillance Type

AHD, Analogue, HDCVI, HDTVI, IP
