AAP B-BRAINY24+

AAP B-BRAINY24+ 24VDC Controller with integrated receiver and battery charger (64 Remote Slots) – Used For Swing Gate Automation

Key Features :-

• Integrated LCD display
• Integrated radio receiver 433.92 MHz 64 codes and 3 encoding systems (Advanced Rolling Code, Rolling Code, Fixed Code
• Removable terminal boards
• Separate limit switch inputs for each motor
• Open, close, step-by-step and pedestrian inputs
• Separate opening-closing and closing photocell inputs
• Stop input
• Input for N.C. or 8K2 sensitive edge
• Encoder Input for 24 Vdc hydraulic motors
• Output for 12 Vdc electric lock
• 2 outputs configurable as open gate indicator, second radio channel, courtesy light, zone light or photocell testing, flashing light, open gate alarm, NC input alarm
• Output for connecting flashing light
• Autoset of operating parameters
• Separate electronic torque adjustment for each motor
• Separate electronic speed adjustment for each motor
• Anti-crushing safety through amperometry detection and encoder management
• Separate slowdowns for each motor in opening and closing phases
• Advantouch system to configure parameters and manage radio transmitters
• Number of maneuvers
• Programming access password
• Maintenance warning
• Built-in battery charger
