Akuvox IT88A
Akuvox IT88A 10″ (10-Inch) Video Intercom Touchscreen Monitor – Android 9.0 OS – Built-in WiFi – Voice Assistant – Built-in 1MP Camera
SKU: IT88A
Categories: Akuvox IP Video Intercoms, Akuvox Video Intercoms, Video Intercoms
Tags: 10 Inch, 2.4GHz Wireless, 5GHz Wireless, AI, Akuvox, Android, Audio, Audio Intercom, Bluetooth, Built-in Mic, Camera, Gate Automation, Gate Control, IP, Monitor, PoE, Relay, SIP, Speaker, Touchscreen, Video Intercom, Voice Assistant, White, WiFi, WiFi 6, Wireless
Akuvox IT88A 10″ (10-Inch) Video Intercom Touchscreen Monitor – Android 9.0 OS – Built-in WiFi – Voice Assistant – Built-in 1MP Camera
Key Features :-
- Display: 10-inch, 1280×800 resolution capacitive touch screen IPS LCD with an aluminum alloy front panel.
- Operating System: Runs on Android 9 OS, which allows for the installation of third-party home automation and other compatible applications.
- Audio and Video: Provides high-definition (HD) two-way audio and video communication with door phones via the SIP 2.0 protocol.
- Built-in Camera: Includes a built-in 1MP CMOS camera.
- Connectivity: Features integrated Wi-Fi (IEEE 802.11 b/g/n) and Bluetooth 4.2 connectivity.
- Power over Ethernet (PoE): Can be powered via an Ethernet cable (802.3af PoE) for simplified installation or an external 12V DC source.
- Smart Features: Includes a built-in smart voice assistant with a 5-meter pickup distance and supports integration with the Akuvox SmartPlus mobile video service for remote access.
- Integration Capabilities: Offers multiple inputs/outputs, including eight channel inputs, two embedded relays, RS485 port support, and compatibility with SIP-capable PBX systems for extensive home automation control.
- Installation: Designed for both wall-mounted and desktop installations (desktop stand optional).
Physical & Power
- Front panel: Aluminium alloy
- RAM / ROM: 2GB / 8GB
- Display: 10 Inch IPS LCD
- Screen: 10 Inch capacitive touch screen
- Wi-Fi: IEEE802.11 b/g/n, @2.4GHz
- BLE: Support BLE 4.2
- Camera: 1MP camera, CMOS
- Memory slot：1 Micro SD slot
- RS485 port: Support
- Relays out: 2
- Bell in: 1
- IO: 8
- Microphone: -26dB
- Speaker: Dual speakers, 4Ω / 3W
- Ethernet ports: 1xRJ45, 10/100Mbps adaptive
- 802.3af Power-over-Ethernet
- 12V DC connector (if not using PoE)
- Tamper resistant: Support
- Installation: Wall-mounted & Desktop
- Dimension: 251×182.5×29.75mm
- Working Humidity: 10~90%
- Working Temperature: -10°C ~ +45°C
- Storage Temperature: -20°C ~ +70°C
Touch Screen Display
- Display Mode: Normally black, Transmissive
- LCD Size: 10inch (Diagonal)
- Aspect Ratio: 16:10
- Resolution: 1280×800
- Contrast ratio: 900:1
- Luminance: 350 cd/m²
- Viewing Angle: 80° Left, 80° Right, 80° Upper, 80° Lower
- Touch Screen: Projected capacitive
Audio
- SIP v1 (RFC2543), SIP v2 (RFC3261)
- Narrowband audio codec: G.711a, G.711μ, G.729
- Broadband audio codec: G.722
- DTMF: In-band, out-of-band DTMF (RFC2833), SIP Info
- Echo Cancellation
- Voice Activation Detection
- Comfort Noise Generator
- Automatic Gain Control
Video
- Streaming formats: H.263 & H.264
Networking
- Protocols support: IPv4, IPv6, HTTP, HTTPS, FTP, TFTP, SNMP, DNS, SNTP, RTSP, SRTP, RTP, TCP, UDP, TLS, ICMP, DHCP, ARP
Deployment & Maintenance
- Auto-Provisioning
- Web management portal
- Web-based packet dump
- Configuration backup / restore
- Firmware upgrade
- System logs (include door access logs)
Voice Assistant
- Voice pickup distance up to 5 meters
- Voice recognition accuracy up to 95%
- Privacy protection with native voice data
- Support English
Application Scenario
- Villas
- Apartment complexes
- Home automation systems
- Modern interiors
