Akuvox R20A-2
Akuvox R20A-2 2-Wire Compact Stylish 2MP IP IR Outdoor Video Intercom Unit – Complies with SIP & ONVIF – IP65 Rated – Built-in Mifare & EM Card-Reader – NFC – Single Relay Output – Supports RS485 & Wiegand
SKU: R20A-2
Categories: Akuvox 2-Wire IP Video Intercoms, Akuvox Video Intercoms, Video Intercoms
Tags: 125KHz, 13.56MHz, 2-Wire, 2MP, Akuvox, Audio, Built-in Mic, Camera, Doorbell, Gate Automation, Gate Control, IP, IP65 Rated, Mifare, NFC, ONVIF, Outdoor, PoE, Relay, RFID Reader, SIP, Speaker, Video Intercom, Weatherproof, Wiegand
Akuvox R20A-2 2-Wire Compact Stylish 2MP IP IR Outdoor Video Intercom Unit – Complies with SIP & ONVIF – IP65 Rated – Built-in Mifare & EM Card-Reader – NFC – Single Relay Output – Supports RS485 & Wiegand
Key Features :-
- 2-pin wire for power supply and network access
- Single speed-dial button with blue backlight
- Linux operation system
- Wide-angle camera: 110º (H), 58º (V)
- Two-way audio communication over IP networks with Echo Cancellation & Noise suppression
- Flush-mounted & surface-mounted
- Complies with SIP & ONVIF
- Supports RS485
- Supports wiegand
- Two relay output
- Supports PoE
- Built-in Mifare (13.56MHz) & EM (125KHz) dual frequency card-reader with NFC support
- Mobile app control by Akuvox SmartPlus App
At a Glance
- Vandal resistant body, with a flush button;
- Wide-angle camera: 110º (H), 58º (V);
- PoE (IEEE802.3af, Power-over-Ethernet);
- Two-way audio communication over IP networks with Echo Cancel feature;
- Complies with SIP standard for easy integration in every SIP capable PBXes;
- Complies with ONVIF standard for easy integration with any network surveillance system;
Physical & Power
- Front panel: Aluminum alloy
- Camera: 2M pixels, automatic lighting
- Button: 1 call button
- Light sensor: Support
- Infrared sensor: Support
- Wiegand port: Support
- RS485 port: Support
- RF card reader: 13.56MHz (with NFC) & 125kHz
- Relays out: 2
- Inputs: 2
- Microphone: -40dB
- Speaker: 4Ω / 3W
- Ethernet port: RJ45, 10/100Mbps adaptive
- 802.3af Power-over-Ethernet
- 12V DC connector (if not using PoE)
- Water-proof & Dust-proof: IP65
- Installation: Flush-mounted or Wall-mounted
- Flush-mounted DIM: 189x120x56.5mm
- Wall-mounted DIM: 145x85x27.5mm
- Working Humidity: 10~90%
- Working Temperature: -30°C ~ +60°C
- Storage Temperature: -40°C ~ +70°C
Audio
- SIP v1 (RFC2543), SIP v2 (RFC3261)
- Narrowband audio codec: G.711a, G.711μ, G.729
- Broadband audio codec: G.722
- DTMF: In-band, out-of-band DTMF (RFC2833), SIP Info
- Echo Cancellation
- Voice Activation Detection
- Comfort Noise Generator
Video
- Sensor: 1/2.7”, CMOS
- Pixels: CIF, QCIF, VGA, 4CIF, 720p, 1080p
- Video codec: H.264
- Video resolution: up to 1920x1080p
- Max. image transfer rate: 1080p – 30fps
- Viewing angle: 110°(H) / 58°(V)
- High intensity IR LEDs for picture lighting during dark hours with internal light sensor
- Compatible to 3rd-Party-Video components, e.g. NVRs
Door Entry Feature
- Relays controlled individually by DTMF tones
- Camera permanently operational
- Auto-night mode with LED illumination
- White balance: auto
- Minimum illumination: 0.1LUX
Networking & Protocol
- Protocols support: IPv4, HTTP, HTTPS, FTP, SNMP, DNS, NTP, RTSP, RTP, TCP, UDP, ICMP, DHCP, ARP
Deployment & Maintenance
- Auto-Provisioning
- Web management portal
- Web-based packet dump
- Configuration backup / restore
- Entry log export
- Access table export / import
- Firmware upgrade
- System logs (include door access logs)
Application Scenario
- Office door phone with on-site or hosted IP-PBX
- Remote site entry over Internet
- Apartment/flat intercom with door access control
