Akuvox 2-Wire IP Video Intercoms, Akuvox Video Intercoms, Video Intercoms
Akuvox R20K-2
Akuvox R20K-2 2-Wire IP 2MP IR H264 Outdoor Video Intercom Unit with Integrated Keypad – Complies with SIP & ONVIF – IP65 Rated – Built-in Mifare & EM Card-Reader – NFC – Single Relay Output – Supports RS485 & Wiegand
SKU: R20K-2
Categories: Akuvox 2-Wire IP Video Intercoms, Akuvox Video Intercoms, Video Intercoms
Tags: 1080P, 125KHz, 13.56MHz, 2-Wire, 2MP, Akuvox, Audio, Built-in Mic, Doorbell, Gate Automation, Gate Control, IP, IP65 Rated, Keypad, Mifare, NFC, ONVIF, Outdoor, PoE, Relay, RFID Reader, SIP, Speaker, Video Intercom, Weatherproof, Wiegand
Akuvox R20K-2 2-Wire IP 2MP IR H264 Outdoor Video Intercom Unit with Integrated Keypad – Complies with SIP & ONVIF – IP65 Rated – Built-in Mifare & EM Card-Reader – NFC – Single Relay Output – Supports RS485 & Wiegand
Key Features :-
- 2-pin wire for power supply and network access
- 2MP Video Camera with 110° horizontal wide angle view
- Integrated keypad
- IP65 rated weatherproof
- Two way audio communication over IP with echo cancellation and noise suppression features
- Complies with SIP & ONVIF
- Linux operating system
- Body material: aluminum
- Built-in motion sensor
- Supports RS485
- Supports wiegand
- One relay output
- Built-in Mifare (13.56MHz) & EM (125KHz) dual frequency card-reader with NFC support
- Mobile app control by Akuvox SmartPlus App
Physical & Power
- Front panel: Aluminum alloy
- Camera: 2M pixels, automatic lighting
- Keypad：Yes
- Light sensor: Support
- Infrared sensor: Support
- Wiegand port: Support
- RS485 port: Support
- RF card reader: 13.56MHz (with NFC) & 125kHz
- Relays out: 1
- Inputs: 1
- Microphone: -40dB
- Speaker: 4Ω / 3W
- Power Interface：1
- Power supply：48VDC two-wire power supply
- Water-proof & Dust-proof: IP65
- Installation: Flush-mounted or Wall-mounted
- Flush-mounted DIM: 226x108x52mm
- Wall-mounted DIM: 185x85x29mm
- Working Humidity: 10~90%
- Working Temperature: -30°C ~ +60°C
- Storage Temperature: -40°C ~ +70°C
Audio
- SIP v1 (RFC2543), SIP v2 (RFC3261)
- Narrowband audio codec: G.711a, G.711μ, G.729
- Broadband audio codec: G.722
- DTMF: In-band, out-of-band DTMF (RFC2833), SIP Info
- Echo Cancellation
- Voice Activation Detection
- Comfort Noise Generator
Video
- Sensor: 1/2.7”, CMOS
- Pixels: CIF, QCIF, VGA, 4CIF, 720p, 1080p
- Video codec: H.264
- Video resolution: up to 1920x1080p
- Max. image transfer rate: 1080p – 25fps
- Viewing angle: 110°(H) / 58°(V)
- High intensity IR LEDs for picture lighting during dark hours with internal light sensor
- Compatible to 3rd-Party-Video components, e.g. NVRs
Door Entry Feature
- Relays controlled individually by DTMF tones
- Camera permanently operational
- Auto-night mode with LED illumination
- White balance: auto
- Minimum illumination: 0.1LUX
Networking & Protocol
- Protocols support: IPv4, HTTP, HTTPS, FTP, SNMP, DNS, NTP, RTSP, RTP, TCP, UDP, ICMP, DHCP, ARP
Deployment & Maintenance
- Auto-Provisioning
- Web management portal
- Web-based packet dump
- Configuration backup / restore
- Entry log export
- Access table export / import
- Firmware upgrade
- System logs (include door access logs)
Application Scenario
- Office door phone with on-site or hosted IP-PBX
- Remote site entry over Internet
- Apartment/flat intercom with door access control
