Akuvox S539
Akuvox S539 2MP PoE IP IR H264 Outdoor Metaverse Video Intercom Unit with 10″ Touchscreen Panel – Android – Face Recognition – Complies with SIP & ONVIF – IP66 & IK08 Rated – Built-in Mifare & EM Card-Reader – Three Relay Output – Supports RS485 & Wiegand
SKU: S539
Categories: Akuvox IP Video Intercoms, Akuvox Video Intercoms, Video Intercoms
Tags: 1080P, 125KHz, 13.56MHz, 2MP, Akuvox, Android, Audio, Built-in Mic, Display, Doorbell, Face Capture, Face Detection, Face Recognition, Gate Automation, Gate Control, IK10 Rated, IP, IP65 Rated, Keypad, Mifare, NFC, ONVIF, Outdoor, PoE, Relay, RFID Reader, SIP, Speaker, Touchscreen, Video Intercom, Weatherproof, Wiegand
Akuvox S539 2MP PoE IP IR H264 Outdoor Metaverse Video Intercom Unit with 10″ Touchscreen Panel – Android – Face Recognition – Complies with SIP & ONVIF – IP66 & IK08 Rated – Built-in Mifare & EM Card-Reader – Three Relay Output – Supports RS485 & Wiegand
Key Features :-
- 2MP Video Camera with 120° horizontal wide angle view
- Face recognition support
- Integrated 10″ LED display – touchscreen panel
- Android based unit
- IP65 rated weatherproof
- IK10 rated vandalproof
- Two way audio communication over IP with echo cancellation and noise suppression features
- Complies with SIP & ONVIF
- Linux operating system
- Body material: aluminum
- Built-in motion sensor
- Supports RS485
- Supports wiegand
- Three relay output
- Supports PoE
- Built-in Mifare (13.56MHz) & EM (125KHz) dual frequency card-reader with NFC support
- Mobile app control by Akuvox SmartPlus App
Physical & Power
- Front Panel: Aluminum
- Display: 10 Inch IPS LCD
- Main Camera: 5M pixels, with starlight
- Light Sensor: Support
- Motion Sensor: Support
- ToF Sensor: Support
- Wiegand Port: Support
- RS485 Port: Support
- Line Out: Support
- RF Card Reader: 13.56MHz & 125kHz
- Relays Out: 3Inputs: 3
- Microphone: 2 Speaker: 2
- Reset Button: 1
- BLE: Support
- Ethernet port: 1xRJ45, 10/100Mbps adaptive
- IEEE 802.3at PoE+
- Power: DC12V / 3A or DC24V / 1.5A
- IP & IK Level: IP66 & IK08
- Installation: Flush-mounted & Wall-mounted
- Flush-mounted DIM: 363.5×179.8x64mm
- Wall-mounted DIM: 367.5x183x35.5mm
- Working Humidity: 10~90%
- Working Temperature: -30°C ~ +55°C
- Storage Temperature: -30°C ~ +70°C
Audio
- SIP v1 (RFC2543), SIP v2 (RFC3261)Narrowband audio codec: G.711a, G.711μ, G.729
- Wideband audio codec: G.722
- DTMF: In-band, out-of-band DTMF (RFC2833), SIP Info
- Echo Cancellation
- Voice Activation Detection
- Comfort Noise Generator
Video
- Sensor: 1/2.7”, CMOS for main camera
- Pixels: CIF, QCIF, VGA, 4CIF, 720p, 1080p
- Video codec: H.264
- Video technology: HDR
- Video resolution: up to 1920 x 1080p
- Max. image transfer rate: 1080p – 30fps
- Viewing angle: 120°(H) / 72°(V)
- Compatible to 3rd-Party-Video components, e.g. NVRs
Networking & Protocol
- Protocols support: IPv4, HTTP, HTTPS, FTP, SNMP, DNS, NTP, RTSP, RTP, TCP, UDP, ICMP, DHCP, ARP
Door Entry Feature
- Android OS for any 3rd party software or customization
- Relays controlled individually by DTMF tones
- Multi-way Unlock: Face, Card, PIN, BLE & QR code
- Camera permanently operational
- Auto-night mode with LED illumination
- White balance: auto
- Minimum illumination: 0.1LUX
Deployment & Maintenance
- Auto-Provisioning
- Web management portal
- Web-based packet dump
- Configuration backup / restore
- Entry log export
- Access table export / import
- Firmware upgrade
- System logs (include door access logs)
