Hikvision DS-2CD2955G0-ISU
Hikvision DS-2CD2955G0-ISU Pro-Series H265 5MP PoE IP IR (8m) 120dB True-WDR 360° Fisheye Indoor Dome Camera – Built-in Mic
SKU: DS-2CD2955G0-ISU
Categories: CCTV / Surveillance, IP 360-Degree Panoramic Fisheye Cameras, IP Cameras, IP Surveillance
Tags: 120dB True-WDR, 360 Degree, 5MP, Built-in Mic, Camera, Dome Camera, Fisheye, H265, Hikvision, IP Camera, IR, Network Camera, Panoramic, PoE
Hikvision DS-2CD2955G0-ISU Pro-Series H265 5MP PoE IP IR (8m) 120dB True-WDR 360° Fisheye Indoor Dome Camera – Built-in Mic
Key Features :-
- Up to 5MP high resolution
- 2560 × 1920 @ 30fps
- H.265, H.265 , H.264 , H.264
- Support 14 display modes
- FOV: horizontal FOV 180°, vertical FOV 180°
- Dual video streams
- DC12V & PoE (802.3af)
- Digital Noise Reduction
- Support on-board storage, up to 128 GB
- Up to 8m IR range
- -S: Audio/Alarm IO
- -U: Built-in Mic
Camera
- Image Sensor: 1/2.7″ Progressive Scan CMOS
- Max. Resolution: 2560 × 1920
- Min. Illumination: Color: 0.017 Lux @ (F2.25, AGC ON),B/W: 0 Lux with IR
- Shutter Time: 1/3 s to 1/100,000 s
- Day & Night: IR cut filter
Lens
- Lens Type: Fixed focal lens, 1.05 mm
- Focal Length & FOV: 1.05 mm, horizontal FOV: 180°, vertical FOV: 180°, diagonal FOV: 180°
- Focus: Fixed
- Lens Mount: M12
- Iris Type: Fixed
- Aperture: F2.25
- Depth of Field: 0.1 m to ∞
DORI
- DORI: D: 21 m, O: 8 m, R: 4 m, I: 2 m
Illuminator
- Supplement Light Type: IR
- Supplement Light Range: Up to 8 m
- Smart Supplement Light: Yes
- IR Wavelength: 850 nm
Video
- Main Stream: 50 Hz: 25 fps（2560 × 1920, 2048 × 1536, 1280 × 960); 60 Hz: 30 fps（2560 × 1920, 2048 × 1536, 1280 × 960）
- Sub-Stream: 50 Hz: 25 fps (640 × 480); 60 Hz: 30 fps (640 × 480)
- Video Compression: Main stream: H.265+/H.265/H.264+/H.264; Sub-stream: H.265/H.264/MJPEG
- Video Bit Rate: 32 Kbps to 16 Mbps
- H.264 Type: Baseline Profile, Main Profile, High Profile
- H.265 Type: Main Profile
- Region of Interest (ROI): 1 fixed region for main stream
Fisheye Display
- Mount Type: Support wall/table/ceiling mounting
Audio
- Audio Type: Mono sound
- Audio Compression: G.711ulaw/G.711alaw/G.722.1/G.726/MP2L2/PCM/AAC-LC
- Audio Bit Rate: 64 Kbps (G.711 ulaw/G.711 alawm/16 Kbps (G.722.1)/16 Kbps (G.726)/32~160 Kbps (MP2L2)/16~64Kbps (AAC-LC)
- Audio Sampling Rate: 8 kHz/16 kHz
- Environment Noise Filtering: Yes
Network
- Protocols: TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6, Bonjour, IPv4, UDP, SSL/TLS
- Simultaneous Live View: Up to 6 channels
- API: Open Network Video Interface (Profile S, Profile T, Profile G),ISAPI
- User/Host: Up to 32 users – 3 user levels: administrator, operator, and user
- Client: iVMS-4200,Hik-Connect,Hik-Central
- Security: Password protection, complicated password, HTTPS encryption, IP address filter, Security Audit Log, basic and digest authentication for HTTP/HTTPS, TLS 1.1/1.2, WSSE and digest authentication for Open Network Video Interface
- Web Browser: Plug-in required live view: IE 10+; Local service: Chrome 57.0+, Firefox 52.0+; Network StorageNAS (NFS, SMB/CIFS)
- Image Settings: Rotate mode, saturation, brightness, contrast, sharpness, white balance, adjustable by client software or web browser
- Day/Night Switch: Day, Night, Auto, Schedule
- Image Enhancement: BLC, 3D DNR
- Wide Dynamic Range (WDR): 120 dB
Interface
- Ethernet Interface: 1 RJ45 10 M/100 M self-adaptive Ethernet port
- On-Board Storage: Built-in memory card slot, support microSD/microSDHC/microSDXC card, up to 256 GB
- Built-in Microphone: -U: Yes
- Audio: 1 input (line in), two-core terminal block, max. input amplitude: 3.3 Vpp, input impedance: 4.7 KΩ, interface type: non-equilibrium; 1 output (line out), two-core terminal block, max. output amplitude: 3.3 Vpp, output impedance: 100 Ω, interface type: non-equilibrium
- Alarm: 1 input, 1 output (max. 12 VDC, 30 A)
- Reset Key: Yes
- Power Output: 12 VDC, max. 100 mA
Event
- Basic Event: Motion detection, video tampering alarm, exception
- Smart Event: Line crossing detection, intrusion detection
- Linkage: Upload to FTP/NAS/memory card,notify surveillance center,send email,trigger recording,trigger capture,trigger alarm output
General
- Power: 12 VDC ± 25%, 0.5 A, max. 6 W,Ø5.5 mm coaxial power plug,reverse polarity protection; PoE: IEEE 802.3af, Class 3, max. 7.5 W
- Material: ADC12
- Dimension: Ø119.9 mm × 41.2 mm (Ø4.7″ × 1.6″)
- Package Dimension: 150 mm × 125 mm × 99 mm (5.9″ × 4.9″ × 3.9″)
- Weight: Approx. 320 g (0.7 lb.)
- With Package Weight: Approx. 500 g (1.1 lb.)
- Language: 13 languages English, Turkish, Polish, Romanian, Czech, Slovak, Traditional Chinese, Thai, Vietnamese, Croatian, Slovenian, Serbian, Ukrainian
- Storage Conditions: -10 °C to 50 °C (-14 °F to 122 °F). Humidity 95% or less (non-condensing)
- Startup and Operating Conditions: -10 °C to 50 °C (-14 °F to 122 °F). Humidity 95% or less (non-condensing)
- General Function: Heartbeat, anti-banding, mirror, password protection
Approval
- EMC: CE-EMC: EN 55032: 2015, EN 61000-3-2:2019, EN 61000-3-3: 2013+A1:2019, EN 50130-4: 2011 +A1: 2014,
RCM: AS/NZS CISPR 32: 2015; IC: ICES-003: Issue 7; KC: KN32: 2015, KN35: 2015
-
Safety: UL: UL 62368-1; CB: IEC 62368-1: 2014+A11; CE-LVD: EN 62368-1: 2014/A11: 2017; BIS: IS 13252 (Part 1): 2010/IEC 60950-1: 2005; LOA: IEC/EN 60950-1
- Environment: CE-RoHS: 2011/65/EU
