Hikvision DS-3E1518P-EI
Hikvision DS-3E1518P-EI Smart-Managed-Series 1U Rackmount Full-Gigabit Network PoE Switch – 16* GbE PoE Ports + 1* GbE Uplink Port + 1* SFP Slot – 230w PoE Power – Supports Extend Mode
Hikvision DS-3E1518P-EI Smart-Managed-Series 1U Rackmount Full-Gigabit Network PoE Switch – 16* GbE PoE Ports + 1* GbE Uplink Port + 1* SFP Slot – 230w PoE Power – Supports Extend Mode
Key Features :-
- 16 × Gigabit PoE port, 1 × Gigabit RJ45 port, 1 x SFP slot
- Total PoE Power Budget 230W
- Support 802.1Q VLAN
- Support PoE watchdog to detect and restart the cameras that do not respond
- Support STP/RSTP Loop prevention
- Support cable detection to locate failure
- Up to 300m Long Range PoE Transmission
- 6KV Surge Protection
Unified cloud management for security systems
Set it all up on a phone
With the help of unified cloud management, even complex deployments no longer require cumbersome equipment, laptops, or monitors. Installers can set up these smart switches using the HPP app in only three steps. It’s quick and easy.
Visualized network topology on a phone
Hikvision smart managed switches can visualize topology on the HPP app. Visualizing a network is now super simple thanks to cloud management.
- Device connection topology
- Bandwidth consumption notification
- Network and device status
- Remote device configuration
Remote troubleshooting and maintenance
No more rushing to the site to troubleshoot problems! Now you can solve system issues remotely using the HPP app. Smart managed switches can locate issues easily and quickly, saving time and costs while improving operational efficiency.
- Device anomaly notifications
- Fault location display
- One-click abnormal port reboot via mobile device
General
- Shell: Metal material
- Net Weight: 2.85 kg (6.28 lb)
- Gross Weight: 3.05 kg (6.72 lb)
- Dimensions (W × H × D): 440.0 mm × 220.8 mm × 44.0 mm (17.32” × 8.69” × 1.73”)
- Operating Temperature: 0 °C to 45 °C (32 °F to 113 °F)
- Storage Temperature: -40 °C to 85 °C (-40 °F to 185 °F)
- Operating Humidity: 5% to 95% (no condensation)
- Relative Humidity: 5% to 95% (no condensation)
- Power Supply: 100~240 V AC, 50/60 Hz, Max. 4 A
- Max. Power Consumption: 250 W
- Power Consumption In Idle: 20 W
Network Parameters
- Ports: 16 × Gigabit PoE port, 1 × Gigabit RJ45 port, 1 × Gigabit fiber optical port
- Port Type: RJ45 port,full duplex,MDIMDI-X adaptive
- Standard: IEEE 802.3,IEEE 802.3ab,IEEE 802.3u,IEEE 802.3x,IEEE 802.3z
- Working Mode: Standard mode (default)
- MAC Address Table: 8K
- Switching Capacity: 56Gbps
- Packet Forwarding Rate: 41.66Mpps
- Internal Cache: 4.1Mbits
PoE Power Supply
- PoE Standard: IEEE 802.3af,IEEE 802.3at
- PoE Power Pin: 8-pin power: 1/2(-), 3/6(+), 4/5(+), 7/8(-)
- PoE Port: PoE: Ports 1 to 16
- Max. Port Power: 30 W
- PoE Power Budget: 230 W
Software Function
- Device Maintenance: Remote upgrade, default parameters recovery, basic network parameters configuration, import and export configuration, time sync
- Port Configuration: Port rate configuration, slow control, and ports enabling
- PoE Watchdog: PoE watchdog: Ports 1 to 16 auto detect and restart the cameras that do not respond.
- Port Mirroring: Supported
- Link Aggregation: Static link aggregation supported for any four ports, and up to eight aggregation groups allowed
- Port Isolation: Ports in an isolation group cannot communicate with each other, but they can communicate with ports outside the isolation group.
- LLDP: LLDP protocol supported for port configuration, global configuration and neighbour discovery
- DHCP: DHCP client
- MAC Address Table Display: Supported
- Super IP: 10.180.190.200
- Cable Detection: Supported
- HPP: Supported
- Port Long-Range Mode: Supported
- Port Statistics: Supported
- Web Management: Supported
Approval
- EMC: FCC (47 CFR Part 15, Subpart B); CE-EMC (EN 55032: 2015, EN IEC 61000-3-2: 2019, EN 61000-3-3: 2013+A1: 2019, EN 50130-4: 2011 +A1: 2014, EN 55035: 2017); IC (ICES-003: Issue 6); RCM (AS/NZS CISPR 32: 2015)
- Safety: UL (UL 60950-1); CB (IEC 60950-1:2005, AMD1:2009, AMD2:2013, IEC 62368-1: 2014 (Second Edition); CE-LVD (EN 60950-1: 2006 + A11: 2009 +A1: 2010+A12: 2011+A2: 2013, EN 62368-1: 2014+A11: 2017)
- Chemistry: CE-RoHS (2011/65/EU); WEEE (2012/19/EU); Reach (Regulation (EC) No.1907/2006)
