Hikvision DS-QAE1A80G1-VB
Hikvision DS-QAE1A80G1-VB Network IP 2-Zone Amplifier – Total 80W Output – Works with HCP
SKU: DS-QAE1A80G1-VB
Categories: Audio & Visual, Audio Products, Network (IP) Amplifiers, Network (IP) Microphones
Tags: Amplifier, Audio, Hikvision, IP, Network, PA (Public Address), Paging
Hikvision DS-QAE1A80G1-VB Network IP 2-Zone Amplifier – Total 80W Output – Works with HCP
Key Features :-
- Supports real-time and scheduled tasks, resume play, and audio material library management
- Support alarm input, arming schedule, and audio linkage, support TTS speech synthesis and text broadcasting, with natural and smooth standard male and female dual audio options
- Support multiple types of audio source input: Bluetooth, USB flash drive, microphone, and RCA, with flexible and convenient operation
- Independent microphone volume control, 2-channel partition volume control
- Support two-channel audio mixing output
- Support ISUP, EZVIZ Cloud and ISAPI protocol
- Adopt high-strength engineering plastics, sturdy and durable
- Integrated functional design, convenient and reliable
Security Protection
Background Music and Queue Calling
Paging and Notifications
Audio Visual Convergence
Function
- Audio Bit Rate: G.711ulaw (64 Kbps) / G.711alaw (64 Kbps) / MP3 (128 Kbps); Sampling bit width: 16 bits
- Speech Synthesis: Language Type: English, Russian, Spanish, Japanese, Thai, Portuguese (Brazil), Korean, French
- Protection Function: short circuit protection, overcurrent protection, over temperature protection, anti-static electricity protection, surge protection, electrical shock protection
Network
- Network Protocol: IPv4, HTTP, HTTPS , SSL/TLS , DNS, NTP, TCP, UDP, IGMP, ICMP, DHCP, ARP, SSH
- Interface Protocol (API): ISAPI, ISUP, RTP
- Client: HikCentral Professional
Audio
- Rated Power: 80 W, 24 VDC
- Frequency Response: 80 Hz to 20 kHz（±3 dB）
- THD and SNR: THD: ≤1%; SNR: ≥100 dB
Interface
- Alarm: 1 alarm input; 1 alarm output
- Ethernet Interface: 1* RJ45 10 M/100 M adaptive Ethernet port
- Local Storage: Built-in 4 GB EMMC (Audio file storage is 1 GB.)
- Audio In:
- MIC 1: -20 dBV, 4 KΩ,unbalance, 6.35 mm jack
- USB 2.0 × 1
- RCA in 1-2: 0 dBV, 5 KΩ, unbalance, RCA pin jack
- Bluetooth
- Audio Out:
- Constant Voltage Output × 2，100 V COM
- RCA Out 1-2: 0 dBV, 100 Ω, unbalance, RCA pin jack
- RCA Cascading: support a cascade of up to 3 amplifiers
- LED Indicator:
- Power indicator (solid white): the device is normally working
- USB flash drive indicator (solid white): the device is in USB mode
- Bluetooth indicator (solid blue): the device is in Bluetooth mode
- Volume Knob: MIC Volume Knob × 1，Partition 1 Volume Knob × 1，Partition 2 Volume Knob × 1
- USB: USB 2.0/3.0; File format: FAT32, maximum capacity: 128 GB; FAT32 file system: maximum partition size: 128 GB, maximum file size: 4 GB.
- Power Interface: Aperture size: Ø2.0 mm
General
- Material: Plastic
- Language: 41 languages: English, French, Spanish, German, Italian, Japanese, Thai, Russian, Portuguese (Brazil), Arabic, Bulgarian, Czech, Danish, Greek, Spanish (Mexico), Estonian, Persian, Finnish, Hebrew, Croatian, Hungarian, Indonesian, Kazakh, Korean, Kirgiz, Lao, Lithuanian, Latvian, Dutch, Norwegian, Polish, Portuguese, Romanian, Slovak, Slovenian, Serbian, Swedish, Turkish, Ukrainian, Uzbek, Vietnamese
- Dimension: 190.8 mm × 230.8 mm × 51.2 mm (7.48″ × 9.06″ × 2.01″)
- Package Dimension: 362 mm × 280 mm × 100 mm (14.25″ × 11.02″ × 3.94″)
- Weight: ≈ 1496.2 g (3.3 lb.)
- With Package Weight: ≈ 2456.2 g (5.4 lb.)
- Color: White
- Packing List: Device × 1, Power Adapter × 1, Power Cord × 1, Regulatory Compliance and Safety Information × 1
- Bluetooth: Bluetooth 5.0, 10 m
- Operating Temperature: -10 °C to 55 °C (14 °F to 131 °F)
- Operating Humidity: ＜90% (No condensation)
- Power Consumption: Standby Consumption: 4.5 W; Annual Average Consumption: Max. Working Consumption: 90 W (based on the average playing time)
