Audio & Visual, Audio Products, Network (IP) Speakers
Hikvision DS-QAZ1606G1-BE
Hikvision DS-QAZ1606G1-BE Network PoE IP Ceiling Speaker – Frameless – 6w Output – Bluetooth – Built-in 64GB eMMC – Built-in Mic – Smart Audio Linkage – Works with Hik-Partner Pro, iVMS-4200, Hik-Connect, HCP
SKU: DS-QAZ1606G1-BE
Categories: Audio & Visual, Audio Products, Network (IP) Speakers
Tags: Audio, Ceiling-Mount, Hikvision, In-ceiling, IP, IP Speaker, Network, PA (Public Address), Paging, PoE, Speaker
Hikvision DS-QAZ1606G1-BE Network PoE IP Ceiling Speaker – Frameless – 6w Output – Bluetooth – Built-in 64GB eMMC – Built-in Mic – Smart Audio Linkage – Works with Hik-Partner Pro, iVMS-4200, Hik-Connect, HCP
Key Features :-
- 6.5 inch network ceiling speaker
- Rated Power: 6W
- Sensitivity (1 m, 1 W): 88 dB
- Max. SPL: 94 dB
- Frequency Response: 140Hz~15kHz (-10dB)
- Supports PoE
- Notes * – This IP speaker can work standalone on it’s own and can be controlled/accessed by Hik-Partner Pro app (for the installers), Hik-connect app (for the end-users) and iVMS-4200 software. It also supports smart-linkage to a Hikvision M-series NVR on Hik-connect app.
Security Protection
Background Music and Queue Calling
Paging and Notifications
Audio Visual Convergence
Protocol
- Network Protocol: IPv4, HTTP, HTTPS , SIP, SSL/TLS , DNS, NTP, TCP, UDP, IGMP, ICMP, DHCP, ARP
Microphone
- Type: MEMS
- Amount: 2
- Frequency Response: 100 Hz to 10 kHz
- Sensitivity: -38dBV/Pa
Speaker
- Impedance: 8Ω
- Rated Power: 6W
- Total Harmonic Distortion (THD): ≤1%
- Sensitivity (1 m, 1 W): 88dB
- Max. Acoustic Pressure: 94dB
- Frequency Response: 140Hz~15kHz (-10dB)
- Speaker Unit: Full frequency: 6.5″ × 1
Function
- Audio Algorithm: AEC, AGC, ANS, DRC
- Audio Bit Rate: G.711ulaw ( 64 Kbps) / G.711alaw (64 Kbps) / MP3 (128 Kbps); Sampling bit width: 16 bits
Network
- Client: Hik-Connect, iVMS-4200, HikCentral Professional, Hik-Partner Pro, NVR, Milestone
Audio
- Number of Sub Speaker:
- 24VDC @ 2.5A, max. 60W: support 6* 6W sub speakers
- IEEE 802.3bt (Hi PoE): support 6* 6W sub speakers
- IEEE 802.3at (PoE): support 0* 6W sub speakers
- IEEE 802.3af (PoE): support 0* 6W sub speakers
- Secondary Speaker Connection Method: Voltage Input
Interface
- Alarm: Alarm in
- Network Interface: RJ45 10 M/100 M Adaptive Ethernet port × 1
- Local Storage: Built-in 64 GB EMMC (Audio file storage is 55 GB.)
- Audio In: 3.5 mm audio interface × 1
- LED Indicator”
- Solid green: normal working
- Flashing green: intercom in progress
- Solid red: start or network disconnection
- Flashing red: upgrading
- Reset: Support
General
- Power: 24 V, 5 A, max. 60 W / IEEE 802.3 bt(Hi PoE) / IEEE 802.3 af(PoE) / IEEE 802.3 at(PoE)
- Material: Main body: PC; base: ABS
- Dimension: φ242.78mm X 192.7mm
- Weight: Approx. 2.7 kg (5.95 lb.)
- Language: 5 languages: English, French, Spanish, German, Italian
- Package Dimension: 305mm × 305mm × 315mm
- With Package Weight: Approx. 2.9 kg (6.49 lb.)
- Packing List:
- Device × 1
- Regulatory Compliance and Safety Information × 1
- 2-pin phoenix connector × 1
- 4-pin phoenix connector ×1
- Bluetooth: Bluetooth 5.0, 10 m
- Operating Temperature: -10 °C to 45 °C
- Operating Humidity: ＜90% (No condensation)
