Networking Products, PoE Switches, Web-smart PoE Switches
TP-Link TL-SG1016PE
TP-Link TL-SG1016PE Jetstream 16-Port Gigabit Ethernet Easy Smart Network PoE Switch with 8 * GbE PoE+ Ports + 8 * GbE LAN Ports – 150w PoE Power Output – Web-Management
SKU: TL-SG1016PE
Categories: Networking Products, PoE Switches, Web-smart PoE Switches
Tags: 16-port, 8x PoE, Gigabit, IP, Network, PoE Switch, Rackmount, TP-Link
TP-Link TL-SG1016PE Jetstream 16-Port Gigabit Ethernet Easy Smart Network PoE Switch with 8 * GbE PoE+ Ports + 8 * GbE LAN Ports – 150w PoE Power Output – Web-Management
Key Features :-
- 16* 10/100/1000Mbps RJ45 ports
- Equipped with 8× PoE+ supported ports to transfer data and power over a single cable
- With a total PoE power budget of 150W,* up to 30W per port
- Works with IEEE 802.3af/at compliant devices
- Automatically reboots your dropped or unresponsive PoE-powered devices with PoE Auto recovery
- Simple network set-up on top of plug-and-play connectivity
- Web-based user interface and management utility simplify configuration
- TP-Link PoE Technology
| Standards and Protocols | IEEE 802.3i, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3x, IEEE 802.1q, IEEE 802.1p |
|---|---|
| Interface | 16× 10/100/1000 Mbps RJ45 Ports AUTO Negotiation/AUTO MDI/MDIX |
| Network Media | 10BASE-T: UTP category 3, 4, 5 cable (maximum 100m) EIA/TIA-568 100Ω STP (maximum 100m) 100BASE-TX: UTP category 5, 5e cable (maximum 100m) EIA/TIA-568 100Ω STP (maximum 100m) 1000BASE-T: UTP category 5, 5e, 6 or above cable (maximum 100m) EIA/TIA-568 100Ω STP (maximum 100m) |
| Fan Quantity | 1 |
| Physical Security Lock | Yes |
| PoE Ports (RJ45) | Standard: 802.3 af/at compliant PoE Ports: Port 1 to Port 8 PoE Power Budget: 150 W |
| Dimensions ( W x D x H ) | 11.6×7.1×1.7 in (294×180×44 mm) |
| Mounting | Rack Mountable/ Desktop |
| Max. Power Consumption | 8.8 W (220 V/50 Hz with no PD connected) 172.26 W (220 V/50 Hz with 150 W PD connected) |
| Max. Heat Dissipation | 30.01 BTU/h (220 V/50 Hz with no PD connected) 587.41 BTU/h (220 V/50 Hz with 150 W PD connected) |
| Switching Capacity | 32 Gbps |
|---|---|
| Packet Forwarding Rate | 23.8 Mbps |
| MAC Address Table | 8K |
| Packet Buffer Memory | 4.1 Mbit |
| Jumbo Frame | 10 KB |
| Quality of Service | Support Port-Based/802.1p/DSCP priority Support 4 priority queues Rate Limit Storm Control |
|---|---|
| L2 Features | IGMP Snooping V1/V2/V3 Static Link Aggregation Port Mirroring Cable Diagnostics Loop Prevention |
| VLAN | Supports up to 32 VLANs simultaneously (out of 4K VLAN IDs) MTU/Port/Tag VLAN |
| PoE | PoE Management Extend Mode PoE Auto Recovery |
| Management Features | Web-based GUI Easy Smart Configuration Utility |
| Transmission Method | Store-And-Forward |
| Certification | FCC, CE, RoHS |
|---|---|
| Package Content | TL-SG1016PE Power Cord Installation Guide Rackmount Kit Rubber Feet |
| System Requirements | Microsoft® Windows® for running Utility |
| Environment | Operating Temperature: 0–40 ℃ (32–104 ℉) Storage Temperature: -40–70 ℃ (-40–158 ℉) Operating Humidity: 10–90% non-condensing Storage Humidity: 5–90% non-condensing |
