Wi-Tek WI-PS505G
Wi-Tek WI-PS505G Unmanaged Multi-Gigabit 2.5Gbps Network PoE Switch with 4* 2.5Gbps PoE Ports + 1* 2.5Gbps Uplink Port – 65w PoE Power
Limited stock on hand – First In First Serve – Special pricing applicable to items in ITPLUS stock only
Wi-Tek WI-PS505G Unmanaged Multi-Gigabit 2.5Gbps Network PoE Switch with 4* 2.5Gbps PoE Ports + 1* 2.5Gbps Uplink Port – 65w PoE Power
Key Features :-
- 4 * 100/1000/2500Mbps RJ45 PoE Ports
- 1 * 100/1000/2500Mbps RJ45 Ethernet Port
- 65W power budget: Port 1: 802.3bt 60W; Port 2-3: 802.3af/at
- 2.5GBASE-T RJ-45 ports provide higher speed
- An ideal solution for all of high-speed devices
- Plug and play, zero configuration
- Works with existing cable: Cat5e, Cat6, and above cable
- Fanless design to ensure a silent environment at your home and office
- Built-in IEEE 802.3az Energy Efficient Ethernet (EEE)
HARDWARE FEATURES
WI-PS505G
Interface
4 100/1000/2500Mbps RJ45 PoE Ports
1 100/1000/2500Mbps RJ45 Ethernet Port
PoE Port
Port 1: Hi-PoE 802.3bt 60W
Port 2-4: 802.3af/at 30W
Network Media
10BASE-T: Cat3.4.5or more UTP(≤250 m)
100BASE-TX: Cat5e or more UTP(≤150 m)
1000BASE-TX: Cat5e or more UTP(≤150 m)
Power Consumption
65W
Ethernet Standard
IEEE 802.3u 100BASEX Ethernet
IEEE 802.3ab 1000BASE-T
IEEE 802.3bz 2.5GBASE-T
Power Supply
DC 52V 1.25A
Exchange Capacity
25Gbps
Packet Forwarding Rate
29.8Mpps
Mac Address Table
16k
Packet Buffer Memory
12Mb
Jumbo Frame
10240 Bytes
Protection Level
6kV ESD Contact discharge
6kV Lightning protection
Transmission Method
Store-And-Forward
Others
Certification
CE、FCC、RoHS
LED Indicator
1G/2.5Gbps link; 10/100Mbps link; PoE; PWR-Power
Package Dimension
270 220 67
Product Dimension
223 113 31
Gross Weight
1.49kg
Net Weight
0.56kg
Package Content
1 × PoE Switch
1 × Power Cord
1 × Power Adapter
1 × Quick Installation Guide
Working Environment
Working Temperature: -10~55°C
Storage Temperature: -40~80°C
Working Humidity: 5%~90%，non-condensing
Storage Temperature: 5%~90%，non-condensing
