ZKTeco SC800

ZKTeco SC800 Metal Standalone IP Access Control Unit with 2.4″ LCD Display – Built-in Mifare Card-Reader + Touchscreen Keypad – Wiegand In/Out

ZKTeco SC800 Metal Standalone IP Access Control Unit with 2.4″ LCD Display – Built-in Mifare Card-Reader + Touchscreen Keypad – Wiegand In/Out

Durability: IP65 water/dust resistance and IK04 vandal-proof metal housing, suitable for harsh outdoor environments.
RFID Capabilities: (Optional) Multi-tech module supports 125kHz and 13.56MHz cards (ID, IC, Felica, Legic, DESfire EV1/EV2, HID Prox/iClass).
User Capacity: Supports up to 50,000 cards (optional 100,000) and 200,000 log events.
Communication & Interfaces: TCP/IP, Wiegand Input/Output, RS485, OSDP (Ver2.1.7), and optional Wi-Fi.
System Functions: Embedded web server for configuration, anti-passback, and access control/time attendance push protocol.
Design: 2.4-inch TFT color screen with a 2.5D tempered glass panel and hidden touch keypad.
Security: Complies with ZKCSBL (ZKTeco Cyber Security Base Line) and supports AES-256 encryption.

Display2.4 inch TFT LCD Color Screen
Operation SystemLinux
Card Capacity50,000 (Optional: 100,000)
Logs Capacity200,000 (Optional: 1,000,000)
User Password6 Digits
RFIDStandard Module: ID Optional Multi-Tech Card Module:
Module 1 Support ID&IC& DESFire EV1/EV2;
Module 2 Support ID&IC& DESFire EV1/EV2&Feliac&Legic&HID Prox;
Module 3 Support ID&IC& DESFire EV1/EV2&Feliac&Legic&HID Prox&HID iclass;
CommunicationTCP / IP, Wiegand, RS485 (for RS485 readers), OSDP (Ver2.1.7), RS232 (only for printer), Wi-FI (Optional)
Wired Network10 / 100 Mbps, Auto MDI / MDI-X
Access Control Interface3rd Party Electric Lock, Door Sensor, Exit Button, Alarm, Doorbell
Auxiliary Interface1 AUX input
Indication LightBreathing light: White, Status light: Red / Green
Hardware1GHz Dual Core CPU, DDR2 64M, Flash 256M
Data ProtectionAES-256 Encryption
KeypadHidden Touch Keypad
Wiegand SignalWiegand In / Out
Standard FunctionsID card, Web sever, Automatic Status Switch, Self-Service Query, DST, 14 Digit User ID, Scheduled Bell, Anti-passback, HTTPS, Protocol convert (AC push to TA push)
Optional FunctionsWi-Fi, Multi-tech Card Module, Printer
Power SupplyDC 12V 3A
Operating Temperature-10°C to 55°C (14°F to 131°F)
Storage Temperature-20°C to 60°C ( -4°F to 140°F)
Operating Humidity10% to 90% RH
Dimensions (L*W*D)143*85*19.8 mm
ProtocolA & C Push (default) / T&A Push
Supported SoftwareZKBio CVAccess
