Hikvision Clearance Specials
CCTV / Surveillance, Clearance, IP Cameras, IP Covert Cameras, IP Surveillance, Special Offers
Hikvision DS-2CD2D25G1-D/NF-2.8MM
Hikvision DS-2CD2D25G1-D/NF-2.8MM Special-series 2MP 1080P Network IP Low-Light (0.002 Lux Colour) 120dB True-WDR Covert Pinhole Board Camera with Cone-Shape Lens – with 2.8mm Fixed Lens
Limited stock on hand – First In First Serve – Special pricing applicable to items in ITPLUS stock only
SKU: DS-2CD2D25G1-D/NF-2.8MM
Categories: CCTV / Surveillance, Clearance, IP Cameras, IP Covert Cameras, IP Surveillance, Special Offers
Tags: 1080P, 120dB True-WDR, 2MP, Camera, Covert Camera, Fixed Lens, H265, Hikvision, IP Camera, Network Camera
Hikvision DS-2CD2D25G1-D/NF-2.8MM Special-series 2MP 1080P Network IP Low-Light (0.002 Lux Colour) 120dB True-WDR Covert Pinhole Board Camera with Cone-Shape Lens – with 2.8mm Fixed Lens
Key Features :-
- Hikvision
- Mini IP Camera
- 1/2.8″ Progressive Scan CMOS
- 2 Megapixel (1920 x 1080) resolution
- 2.8mm Lens
- Low-light – Colour 0.002 Lux
- Compression H.265+ / H.265 / H.264+ / H.264
- RJ-45 10/100 Mbps
- Audio line-in input
- WDR (120 dB)
- 3D-DNR
- WEB, CMS, Smartphone and NVR interface
- ONVIF Compatible
Camera
- Image Sensor: 1/2.8″ Progressive Scan CMOS
- Max. Resolution: 1920 × 1080
- Min. Illumination: Color: 0.002 Lux @ (F1.2, AGC ON)
- Shutter Time: 1/3 s to 1/100,000 s
Lens
- Focal Length & FOV: 2.8 mm: horizontal FOV: 93.9°, vertical FOV: 51.7°, diagonal FOV: 109.3°
- Lens Mount: Mini
- Iris Type: Fixed
- Aperture: 2.8 mm: F2.5
DORI
- DORI: 2.8 mm: D: 47.9 m, O: 19 m, R: 9.6 m, I: 4.8 m
Video
- Main Stream: 50 Hz: 50 fps (1920 × 1080, 1280 × 720); 60 Hz: 60 fps (1920 × 1080, 1280 × 720)
- Sub-Stream: 50 Hz: 25 fps (640 × 480, 640 × 360, 320 × 240); 60 Hz: 30 fps (640 × 480, 640 × 360, 320 × 240)
- Third Stream: 50 Hz: 1 fps (1920 × 1080, 1280 × 720, 640 × 480, 640 × 360, 320 × 240); 60 Hz: 1 fps (1920 × 1080, 1280 × 720, 640 × 480, 640 × 360, 320 × 240)
- Video Compression: Main stream: H.265 / H.264; Sub-stream: H.265 / H.264 / MJPEG; Third stream: H.265 / H.264
- H.264 Type: Baseline Profile / Main Profile / High Profile
- H.265 Type: Main Profile
- Bit Rate Control: CVR / BVR
- Scalable Video Coding (SVC): H.264 and H.265 encoding
- Region Of Interest (ROI): Support 1 fixed region for main stream
Audio
- Audio Type: Mono
- Audio Compression: G.711/G.722.1/G.726/MP2L2/PCM/AAC
- Audio Bit Rate: 64 Kbps (G.711)/16 Kbps (G.722.1)/16 Kbps (G.726)/32 to 192 Kbps (MP2L2)/16 to 64 Kbps (AAC)
- Audio Sampling Rate: 8 kHz/16 kHz/32 kHz
- Environment Noise Filtering: Yes
Network
- Protocols: TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, NTP, UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6, UDP, Bonjour, SSL/TLS
- Simultaneous Live View: Up to 15 channels
- API: Open Network Video Interface, ISAPI, SDK, ISUP 5.0
- User/Host: Up to 32 users – 3 level: administrator, operator, and user
- Network Storage: NAS (NFS, SMB/CIFS)
- Client: iVMS-4200, Hik-Connect
- Web Browser: Plug-in required live view: IE10, IE11; Plug-in free live view: Chrome 57.0+, Firefox 52.0+; Local service: Chrome 57.0+, Firefox 52.0+
- Image Parameters Switch: Yes
- Image Settings: Saturation, brightness, contrast, and sharpness adjustable by client software or web browser
- Day/Night Switch: Day, Night, Auto, Schedule
- Wide Dynamic Range (WDR): 120 dB
- Image Enhancement: BLC, HLC, defog, 3D DNR
- Privacy Mask: Yes
Interface
- Ethernet Interface: 1x RJ45 10 M/100 M self-adaptive Ethernet port
- Audio: 1 input (line in), 1 output (line out)
- Reset Key: Yes
Event
- Basic Event: Motion detection, video tampering alarm, exception (HDD full, HDD error, network disconncected), video quality diagnosis
- Smart Event: Intrusion detection, line crossing detection, region entrance detection, region exiting detection, unattended baggage detection, object removal detection; Audio exception detection, defocus detection, scene change detection
- Linkage: Upload to FTP/NAS/memory card, notify surveillance center, send email, trigger recording, trigger capture, audible warning
General
- Power: 12VDC ± 20%, 0.13 A, max. 1.5 W, Ø5.5 mm coaxial power plug
- Dimension: 31.5 mm × 31.5 mm × 39.7 mm (1.2″ × 1.2″ × 1.6″)
- Package Dimension: 130 mm × 104 mm × 85 mm (5.1″ × 4.1″ × 3.3″)
- Approx. 93 g (0.2 lb.)
- With Package Weight: Approx. 202 g (0.4 lb.)
- Storage Conditions: -30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing)
- Startup And Operating Conditions: -30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing)
- Language: 18 languages: English, Traditional Chinese, Russian, Turkish, Japanese, Korean, Thai, Vietnamese, Estonian, Bulgarian, Hungarian, Czech, Slovak, French, Italian, German, Spanish, Portuguese
- General Function: One-key reset, heartbeat, mirror, password protection, privacy mask, rotate, watermark, IP address filter
Approval
- EMC: FCC (47 CFR Part 15, Subpart B); CE-EMC (EN 55032: 2015, EN 61000-3-2:2019, EEN 61000-3-3:2013+A1:2019, EN 50130-4: 2011+A1: 2014); RCM (AS/NZS CISPR 32: 2015); IC (ICES-003: Issue 7); KC (KN 32: 2015, KN 35: 2015)
- Safety: UL (UL 62368-1); CB (IEC 62368-1:2014+A11); CE-LVD (EN 62368-1:2014/A11:2017); BIS (IS 13252(Part 1):2010/ IEC 60950-1 : 2005); LOA (IEC/EN 60950-1)
- Environment: CE-RoHS (2011/65/EU); WEEE (2012/19/EU); Reach (Regulation (EC) No 1907/2006)
