Wi-Tek WI-POE11S-48V

Wi-Tek WI-POE11S-48V Easy Plug n Play PoE Splitter -> 48V PoE Input on RJ45 -> 12VDC 1A DC + LAN Output

SKU: WI-POE11S-48V Categories: , Tags: , , , , ,

Wi-Tek WI-POE11S-48V Easy Plug n Play PoE Splitter -> 48V PoE Input on RJ45 -> 12VDC 1A DC + LAN Output

Features :-

  • 2 * 100Mbps RJ45 Ports with 1 PoE Input and 1 PoE Output
  • IEEE 802.3af/at compliant
  • Delivers power up to 100 meters
  • 12V 1A DC Output
  • Plug-and-Play, requires no configuration

Wi-Tek Product-Link -> WI-PoE11S-48V

HARDWARE FEATURES

WI-POE11S-48V

Interface

1 10/1000Mbps PoE RJ45 Port

1 10/1000Mbps Ethernet Port

Network Media

10BASE-T: UTP category 3, 4, 5 cable (Max 100m)

EIA/TIA-568 100Ω STP (Max 100m)

100BASE-TX: UTP category 5, 5e cable (Max 100m)

EIA/TIA-568 100Ω STP (Max 100m)

Power Supply

48V PoE IN

Data In/Out

1 10/1000Mbps Data Out

Power In/Out Port

12V DC Out

PoE PIN

4/5(+) 7/8(-) or 1/2(+) 3/6(-)

PoE Consumption

48V 24W

LED Indicator

Power/Link

DIP Switch

N/A

Fan Quantity

Fanless

Background Bandwidth

2Gbps

Transmission Method

Store-And-Forward

Protection Level

6kV Lightning protection

6kV ESD Contact discharge

Advanced Functions

Mac Address Auto-Learning And Auto-Aging

Store and forward

IEEE 802.3x  flow control for

Full-duplex Mode

Backpressure for Half-duplex Mode

OTHERS

Certification

CE, FCC, RoHS

DeviceDimension

209×20×20mm

Net Weight

0.05kg

Package Contents

1 x PoE Switch

1 x Power Cord

1 x Quick Installation Guide

Operating Temperature

-10°C~55°C
