Hikvision DS-KAD706-S

Hikvision DS-KAD706-S 2-Wire IP Intercom Network Distributor Cascade Junction Box – DINRAIL Mount – 6x 2-Wire Cascade Ports – To Connect to Other DS-KAD706-P / DS-KAD706-SP – PSU To Be Purchased Separately

  • Hikvision DS-KAW60-2N

    Hikvision DS-KAW60-2N 24VDC Din-Rail Mount Power Supply for DS-KAD706 & DS-KAD706-S Controller / Distributor

This product is currently unavailable.

Hikvision DS-KAD706-S 2-Wire IP Intercom Network Distributor Cascade Junction Box – DIN-RAIL Mount – 6x 2-Wire Cascade Ports – To Connect to Other DS-KAD706-P / DS-KAD706-SP

Features :-

  • 2-wire IP distributor
  • 6x 2-wire cascade interfaces without device power supply
  • 6x Interface indicators, 1 RJ-45 Interface, 1 Reset button
  • Din rail mounting, 24VDC
  • Hikvision Intercom Online Designer Tool

Device Interfaces

  • Network Interface: 1x RJ45 (1-ch reserved terminal and 1 for WAN access)
  • Two-Wire Interface: 6-ch for data exchanging
  • Signal Indicator: 6 indicators for displaying 6-ch signals
  • Power Indicator: 1
  • Reset: 1

General

  • Power Supply: 24VDC
  • Power Consumption: < 7 W
  • Working Temperature: -10 °C to 50 °C (14 °F to 122 °F)
  • Working Humidity: 10% to 90%
