Hikvision DS-KD-KP

Please login for price

Hikvision DS-KD-KP IP Video Intercom Keypad Module

Description

Hikvision DS-KD-KP IP Video Intercom Keypad Module

Features :-

  • Keypad module
  • Module connection with RS-485
  • IP65, Backlight compensation
  • Flush mounting
  • Surface mounting
  • 98.21mm x 100.21mm x 33.7mm
  • Unlock door via swiping card
  • Powered by other module (Power input: 12VDC, Power output: 12VDC)

System Parameters

  • Processor: Embedded MCU Processor

General

  • Power Consumption: ≤ 2 W
  • Output Power: 12 VDC (powered for the other module)
  • IP Protection Level: IP65, IK7
  • Working Temperature: -40° C to +55° C(-40° F to 131° F)
  • Working Humidity: 10% to 95%
  • Dimensions: 98.5 mm × 100 mm × 34.2 mm (3.87″ × 3.95″ × 1.33″)
  • Weight: 529 g (with packaging) 265 g (without packaging)

Device Interfaces

  • Module Connecting: 2 (1 input, 1 output)
  • Debug: 1
