ZKTeco X10
ZKTeco X10 IP66-Rated Weatherproof Standalone IP Smart Access Control Controller / Reader – Durable Zinc Alloy IP66-Rated Metal Casing – 12VDC Powered – WiFi (2.4GHz) – Dual-Frequency Support (125KHz EM + 13.56MHz MiFare) – Built-in Fingerprint Reader + Touch Keypad – Wiegand – Bluetooth – Remote Management by ZLink App
SKU: X10
Categories: Access Control, Access Control Readers, Dual Frequency Readers, Single Door Standalone - IP & Non-IP
Tags: 125KHz, 13.56MHz, 2.4GHz Wireless, Access Control, Armatura, Bluetooth, Controller, Fingerprint, IP, IP66 Rated, Mifare, Minerva IoT, Network, Reader, Standalone, Touch Keypad, Weatherproof, Wiegand, WiFi, ZKBio ZLink, ZKTeco
ZKTeco X10 IP66-Rated Weatherproof Standalone IP Smart Access Control Controller / Reader – Durable Zinc Alloy IP66-Rated Metal Casing – 12VDC Powered – WiFi (2.4GHz) – Dual-Frequency Support (125KHz EM + 13.56MHz MiFare) – Built-in Fingerprint Reader + Touch Keypad – Wiegand – Bluetooth – Remote Management by ZLink App
Key Features :-
- Durable Build: Housed in a zinc alloy shell with an IP66 rating, it is highly resistant to dust and water, allowing round-the-clock operation in extreme weather.
- Multi-Verification Methods: Grants access via fingerprint, custom PIN codes (4-10 digits), and physical keys.
- Dual-Frequency Card Reader: Supports both 125kHz (ID) and 13.56MHz (IC) card modules simultaneously for ultimate flexibility.
- Remote Management: Features built-in Wi-Fi and Bluetooth 5.0, allowing you to connect directly to the ZKBio Zlink mobile app to manage access and unlock doors remotely.
- Biometric Performance: Highly responsive fingerprint sensor that verifies authorized users in less than 0.3 seconds with an ultra-low False Acceptance Rate (FAR).
- Wiegand Compatibility: Supports Wiegand input, allowing it to function as a smart reader alongside standard access control panels.
- Model: X10
- Authentication Method: Fingerprint / Card / Password (Physical Touch Keypad )
- User Capacity: 500 (1:N) (Standard )
- Card Capacity: 500 (1:N) (Standard )
- Fingerprint Template Capacity: 500 (1:N) (Standard)
- Transaction Capacity: N/A (Cloud sync via ZKBio Zlink)
- Max. User Password Length: Support 4 to 10 Digit number (Factory Default: 4 digits)
- Biometric Verification Speed: less than 0.3 sec (Fingerprint)
- False Acceptance Rate (FAR) %: FAR ≤ 0.0001%
- False Rejection Rate (FRR) %: FRR ≤ 0.01%
- Card Type: ID & IC Card @125 kHz & 13 .56 MHz (Standard)
- Communication: Wi-Fi (IEEE802 .11 b/g/n) @ 2.4 GHz / Bluetooth 5.0; Wiegand (26-44bits Input) * 1; Electric Lock * 1, Door Sensor * 1, Exit Button * 1, Doorbell * 1
- Standard Functions:
-
- Access Control, Buzzer, Multiple Verification Methods
- LED status indicators: Orange: Programming; Green:Verification successful; Red: Standby
- Verification Fail 3 Beeps
- Operation Error: 3 Beeps; No Indicator
-
- Power Supply: DC 12V 0 .15A
- Operating Temperature: -25°C to 60°C
- Operating Humidity: 10% to 90% RH (Non-condensing)
- Dimensions: 160mm * 45mm * 22mm (L*W*H)
- Gross Weight: 0.46Kg
- Net Weight: 0.37Kg
- Supported Software: Mobile APP: ZKBio Zlink
- Installation: Wall-mount
- Housing Material: Zinc Alloy
- Ingress Protection Rating: IP66 (waterproof and dustproof )
- Certifications: ISO14001, ISO9001, CE, Equivalent to RoHS
- Factory ID: AC01-FL40H-01
