Hikvision DS-KH8520-WTE1/White

Hikvision DS-KH8520-WTE1/White PoE IP 10″ (10-Inch) Touchscreen Indoor Intercom Video Monitor – Audio & Video Support – Built-in WiFi

Hikvision DS-KH8520-WTE1/White PoE IP 10″ (10-Inch) Touchscreen Indoor Intercom Video Monitor – Audio & Video Support – Built-in WiFi

Features:-

  • 10.1-inch TFT touch screen with 1024 × 600 resolution
  • Convenient Hik-Connect APP Mobile Control
  • Receive calls, open the door and live view remotely
  • Easy to use without PC
  • Easy wizard for quick set up
  • Configure the whole system on one touch screen
  • Rich functions and extensions
  • Live-view of the door station and cameras in public areas
  • Support voice messages when no response from the indoor station
  • Receive alarms by linkage with a alarm system and notify the center to handle in time
  • Elevator access control
  • Hikvision Intercom Online Designer Tool

Hikvision Product-Link -> DS-KH8520-WTE1



System Parameters

  • Operation System: Embedded Linux operation system
  • Memory: 128 MB
  • Flash: 32 MB

Alarm Parameters

  • Relay Output: 2

Network Parameters

  • Network Protocol: TCP/IP, SIP, RTSP
  • Network Interface: 1 RJ-45 10/100 Mbps self-adaptive
  • Wired Network Interface: 10/100 Mbps self-adaptive
  • Wireless Network Interface: Wi-Fi 802.11b/g/n

Audio Parameters

  • Audio Input: Built-in omnidirectional microphone
  • Audio Output: Built-in loudspeaker
  • Audio Compression Standard: G.711 U
  • Audio Compression Rate: 64 Kbps
  • Audio Quality: Noise suppression and echo cancellation

General

  • Power Supply: IEEE802.3af, standard PoE 12 VDC/1 A
  • Power Consumption: ≤ 6 W
  • Working Temperature: -10 °C to 55 °C (14 °F to 131 °F)
  • Working Humidity: 10% to 90%
  • Weight: 1118 g (with packaging) 660 g (without packaging)
  • Dimensions: 254 mm × 166 mm × 14.7 mm (10.0″ × 6.5″ × 0.58″)
  • Material: IPC + ABS

Display Parameters

  • Display Screen: 10.1-inch colorful TFT screen
  • Display Resolution: 1024 × 600
  • Operation Method: Capacitive touch screen

Device Interfaces

  • Alarm Input: 8-ch alarm inputs
  • TF Card: Max to 32 G, SD 2.0 or lower version
  • RS-485: 1

Hikvision Intercom Designer Tool -> Hikvision Intercom Design Tool

Hikvision App Store – https://appstore.hikvision.com/
