Omada Networks ER603WP-4G-Outdoor
Omada Networks ER603WP-4G-Outdoor 4G/LTE N300 Outdoor PoE Gateway -300Mbps on 2.4GHz WiFi – PoE / 12VDC Powered – Centralized Management – Omada App – Supports Omada EAP Mesh and Fast Roaming
Omada Networks ER603WP-4G-Outdoor 4G/LTE N300 Outdoor PoE Gateway -300Mbps on 2.4GHz WiFi – PoE / 12VDC Powered – Centralized Management – Omada App – Supports Omada EAP Mesh and Fast Roaming
Key Features :-
- 4G Cat4 up to 150 Mbps*
- Wi-Fi 4, Support 300 Mbps on 2.4 GHz†
- 3× Gigabit WAN/LAN Ports (2× PoE Out, 1× PoE In)
- 1× Nano SIM Card Slot
- 802.3af/at/bt PoE/Passive PoE/DC Power Supply
- IP55 Weatherproof & 4 kV Lightning Protection**
- Load Balancing between 4G and Ethernet WAN
- IPSec/PPTP/L2TP/OpenVPN/WireGuard/GRE§ VPN
- Centralized Cloud Management△
- Supports Omada EAP Mesh: Allows Omada Access Points (EAPs) to connect wirelessly to each-other, extending WiFi coverage without requiring Ethernet cables for every node.
- Supports Fast Roaming: Enables wireless devices to switch between APs quickly and seamlessly also preventing connection drops during transitions ensuring a strong stanle signal.
| 4G | |
|---|---|
| Network Type | LTE Band of EU: 4G LTE-FDD: B1/B3/B5/B7/B8/B20/B28 (2100/1800/850/2600/900/800/700) 4G LTE-TDD: B38/B40/B41 (2600/2300/2500 MHz) 3G HSPA+/HSDPA/HSUPA/WCDMA: B1/B5/B8 (2100/850/900 MHz) |
| SIM Type | 1 Nano SIM slot (CAT4 4G) |
| Frequency | • Downlink: 150 Mbps • Uplink: 50 Mbps |
| SECURITY | |
|---|---|
| Access Control | • Source/Destination IP Based ACL • Stateful ACL • IPv4/IPv6 ACL • National Based ACL |
| DNS Proxy | DNSSEC, DoH, DoT, DNS Override |
| Filtering | • Web Group Filtering§ • URL Filtering • Web Security§ |
| Attack Defense | • TCP/UDP/ICMP Flood Defense • Block TCP Scan (Stealth FIN/Xmas/Null) • Block Ping from WAN |
| ARP Inspection | • Sending GARP Packets • ARP Scanning§ • IP-MAC Binding • ARP Detection |
| VPN | |
|---|---|
| GRE | √ (Only in Standalone Mode) |
| IPsec VPN | • 6 IPSec VPN Tunnels • LAN-to-LAN, Client-to-LAN • Main, Aggressive Negotiation Mode • DES, 3DES, AES128, AES192, AES256 Encryption Algorithm IPsec • Failover • IKE v1/v2 • MD5, SHA1, SHA-256, SHA2-384, SHA2-256 and SHA2-512 • Authentication Algorithm NAT Traversal (NAT-T) • Dead Peer Detection (DPD) • Perfect Forward Secrecy (PFS) |
| PPTP VPN | • PPTP VPN Server • PPTP VPN Client (6) • 6 Tunnels • PPTP with MPPE Encryption |
| L2TP VPN | • L2TP VPN Server • L2TP VPN Client (6) • 6 Tunnels • L2TP over IPSec |
| OpenVPN | • OpenVPN Server • OpenVPN Client (3) • 18 OpenVPN Tunnels • “Certificate + Account” Mode • Full Mode |
| WireGuard VPN | √ |
| SD-WAN | √ (Only in Controller Mode) |
| HARDWARE FEATURES | |
|---|---|
| Interface | 3 Gigabit WAN/LAN Ports |
| Network Media | • 10BASE-T: UTP category 3, 4, 5 cable (Max 100 m) EIA/TIA-568 100Ω STP (Max 100 m) • 100BASE-TX: UTP category 5, 5e cable (Max 100 m) EIA/TIA-568 100Ω STP (Max 100 m) • 1000BASE-T: UTP category 5, 5e, 6 cable (Max 100 m) |
| Button | Reset Button |
| Power Supply | Passive/802.3af/at/bt PoE; 12V/1A Adapter (A passive PoE adapter is provided) |
| PoE Standard | • Passive/802.3af/at/bt PoE in for port 1 • Passive/802.3af/at PoE out for port 2-3※ |
| Wi-Fi Frequency & Signal Rate | 2.4 GHz: 300 Mbps |
| Flash | 128 MB NAND |
| DRAM | 256 MB DDR3 |
| LED | 4G Signal, WLAN. WAN/LAN, SYS |
| Dimensions ( W x D x H ) | 4.0 × 1.5 × 6.9 in (100.4 × 38.7 × 174.8mm)(excluding antennas) |
| Antenna | 2 internal Wi-Fi antennas 2 external LTE antennas |
| Mounting | Wall/Pole Mounting (Kits included) |
| Max. Power Consumption | • 10 W without PoE • 62 W with PoE |
| PERFORMANCE | |
|---|---|
| Concurrent Session | 50,000 |
| New Sessions /Second | 2,028 |
| NAT (Static IP) | 944.785 Mbps / 939.201 Mbps |
| NAT(DHCP) | 944.545 Mbps / 927.491 Mbps |
| NAT(PPPoE) | 939.278 Mbps / 928.516 Mbps |
| NAT (L2TP) | 432.126 Mbps / 355.712 Mbps |
| NAT (PPTP) | 513.104 Mbps / 457.323 Mbps |
| 66 Byte Packet Forwarding Rate | 1,419,519 pps / 1,418,731 pps |
| 1,518 Byte Packet forwarding rate | 81,068 pps / 81,068 pps |
| IPsec VPN Throughput | • ESP-SHA1-AES256: 192.432 Mbps • ESP-SHA256-AES256: 195.445 Mbps • ESP-SHA384-AES256: 48.55 Mbps • ESP-SHA512-AES256: 48.363 Mbps |
| GRE | • Unencrypted: 425.292 Mbps • Encrypted: 164.058 Mbps |
| WireGuard VPN | 50.175 Mbps |
| OpenVPN | 11.369 Mbps |
| L2TP VPN Throughput | • Unencrypted: 370.822 Mbps • Encrypted: 144.05 Mbps |
| PPTP VPN Throughput | • Unencrypted: 408.038 Mbps • Encrypted: 35.912 Mbps |
| Management Features | |
|---|---|
| Omada App | Yes |
| Centralized Management | • Omada Cloud-Based Controller • Omada Hardware Controller • Omada Software Controller |
| Cloud Access | Yes |
| Service | Dynamic DNS (Dyndns, No-IP, Peanuthull, Comexe, DDNS Customization) |
| Maintenance | • Web Management Interface • Remote Management • Export & Import Configuration • SNMP v1/v2c/v3 • Diagnostics (Ping & Traceroute) • NTP Synchronize§ • Port Mirroring • CLI (only in Standalone Mode) • Syslog Support |
| Management Features | Automatic Device Discovery Intelligent Network Monitoring Abnormal Event Warnings Unified Configuration Reboot Schedule Captive Portal Configuration ZTP (Zero-Touch Provisioning) |
| WIRELESS FEATURES | |
|---|---|
| Advanced Features | • WPA/WPA2 Personal, WPA/WPA2 Enterprise • Multiple SSIDs: 8 in total (8 per radio) • Rate Limit: Based on SSID/Client |
| Guest Network | Support |
| BASIC FUNCTIONS | |
|---|---|
| LAN DNS | LAN DNS |
| WAN Connection Type | • Static IP • Dynamic IP • PPPoE (supports MRU Configuration) • PPTP • L2TP |
| MAC Clone | Modify WAN Address |
| DHCP | • DHCP Server • DHCPv6 PD Server§ • DHCP Options Customization • DHCP Address Reservation • Multi-IP Interfaces • Multi-Net DHCP • WAN DHCP 60 |
| Stateful ACL | √ |
| Quality of Service | √ |
| Bridge VLAN | √ |
| SMS | Receive/Send SMS |
| mDNS Repeater | √ |
| IPv6 | StaticIP / SLAAC / DHCPv6 / PPPoE / 6to4Tunnel / PassThrough / Non-Address mode |
| VLAN | 802.1Q VLAN |
| IPTV | IGMP v2/v3 Proxy, Custom Mode, Bridge Mode |
| Advanced Features | |
|---|---|
| Bandwidth Control | IP-based Bandwidth Control |
| Load Balance | • Intelligent Load Balance • Application Optimized Routing • Link Backup (Timing, Failover) • Online Detection |
| NAT | • One-to-One NAT • Multi-Net NAT • Virtual Server • Port Triggering§ • NAT-DMZ • FTP/H.323/SIP/IPSec/PPTP ALG • UPnP • Disable NAT |
| Routing | • Static Routing • Policy Routing • RIP§ • OSPF§ |
| Session Limit | IP-based Session Limit |
| AUTHENTICATION | |
|---|---|
| Web Authentication | • No Authentication • Simple Password • Hotspot (Local User / Voucher# / SMS# / Radius#) • External Radius Server • External Portal Server# • LDAP |
| OTHERS | |
|---|---|
| Certification | CE, RoHS |
| Package Content | • ER603WP-4G-Outdoor • Mounting Kits • Passive PoE Adapter • Quick Installation Guide |
| Environment | • Operating Temperature: -30°C–60 °C (-22 °F–140 °F) • Storage Temperature: -40 °C–70 °C (-40 °F–158 °F) • Operating Humidity: 5%–95% non-condensing • Storage Humidity: 5%–90% non-condensing |
TP-Link Omada Support Articles
Key Reasons to Choose Omada Networks
1. Centralized Management
Omada’s Software Defined Networking (SDN) platform allows you to manage routers, switches, and wireless access points from a single dashboard instead of configuring each device separately.
2. Cloud-Based Monitoring
You can remotely monitor and manage customer sites from anywhere using the Omada cloud platform and mobile app, making it ideal for MSPs and IT providers.
3. No Ongoing License Fees
Unlike some enterprise networking brands, Omada offers cloud management without recurring per-device licensing costs, reducing long-term ownership expenses.
4. Easy Multi-Site Deployment
Zero-touch provisioning allows devices to be shipped directly to a site and automatically configured when connected to the internet. This is particularly useful for chain stores, schools, and distributed businesses.
5. Complete Ecosystem
Omada offers:
- Security gateways/routers
- Managed PoE switches
- Indoor Wi-Fi access points
- Outdoor Wi-Fi access points
- Hardware controllers
- Software controllers
All devices integrate into a single management platform.
6. Strong Wi-Fi Performance
Modern Omada access points support:
- Wi-Fi 6
- Wi-Fi 6E
- Wi-Fi 7
- Seamless roaming
- Mesh networking
- High-density client environments
This makes them suitable for offices, schools, hotels, and apartment complexes.
7. Advanced Business Features
Omada supports:
- VLANs
- Guest networks
- VPNs
- Access Control Lists (ACLs)
- 802.1X authentication
- Traffic monitoring
- QoS
- Network segmentation
These features are important for cybersecurity and network performance.
8. Excellent Value for Money
Many installers compare Omada with:
- Ubiquiti
- Grandstream
- Cisco
- Aruba
Omada generally provides similar core SMB functionality at a lower hardware cost.
For Security & IT Professionals
Since you work with surveillance and IT systems, Omada is particularly attractive because:
- PoE switches can power IP cameras, access-control devices, intercoms, and APs.
- VLANs can isolate CCTV traffic from office networks.
- Remote management reduces support visits.
- Multi-site monitoring simplifies customer support.
- High-power PoE models support modern PTZ cameras and Wi-Fi bridges.
For many New Zealand installers, Omada is often the best balance of cost, features, and manageability, especially when compared with higher-priced enterprise networking brands.
